D-link cat5e utp network cable with 4pairs 24awg solid cable

D-link cat5e utp network cable with 4pairs 24awg solid cable

1 Piece/Pieces (Min. Order) Contact Now
DESCRIPTION Datasheet


1.Fast and reliable connection
2.Twisted pairs with bright color for easy recognition
3.Ripcord and foot-mark for convenient use
4.Smooth jacket for easy pulling in tight space
5.Colors: Light gray, blue, white or as per customer's requirements

6.Passing Fluke test is optional

7.OEM and ODM

8.Sample available



Specification:

 1. Conductor:

       Material: Bare Copper (CCA/CCS)

       Type: Solid

       Diameter: 0.50mm

       Gauge: 24AWG

       No.of Pair: 4 Pair

2. Insulation:

        Material: HDPE

        Diameter: 0.92 ± 0.02 mm

Pair1: Orange/White Orange
Pair2: Blue/ White Blue
Pair3: Green/ White Green
Pair4: Brown/White Brown



3.Shield:

         Al Mylar Foil

4. Filler:

       PET tape+rip cord

5. Drain wire:

        Tinned Copper

6. Jacket (Sheath):

       Material: PVC

       Diameter: 5.5 ± 0.2 mm

       Color: Black, Blue, Grey or On request

7.Application:

          100Base-TX, 100VG-AnyLan, 1000Base-T, ATM, Noisy Environment

8.Standard:

           TIA/EIA-568B
