M8 4 Pin Female Straight Connector Aviation Socket with Yellow Cable

M8 4 Pin Female Straight Connector Aviation Socket with Yellow Cable

10 Pieces Minimum Order Contact Now
DESCRIPTION Datasheet
M8 4 Pin Female Straight Connector Aviation Socket with Yellow Cable.jpgM8 4 Pin Female Straight Connector Aviation Socket with Yellow Cable2.jpgM8 4 Pin Female Straight Connector Aviation Socket with Yellow Cable3.jpg

Product Details

Model Number:TK0198

Brand Name:Totek

Origin:China (mainland)

Key Specifications/Special Features:

Key specifications/special features:

1. Description:
M8 connector is designed for the device connection for sensor/actuator boxes, field-bus modules and industrial controllers
It provides with 3, 4, 5, 6, 8 contacts configuration cable cord sets and panel receptacles, most of the connectors are either factory PUR/PVC cable over molded or supplied with attached wire leads, 360°EMC shielding is available as option
With 8mm threaded joint, quick and easy mating and locking, even in places difficult to reach, anti-vibration locking design

2. Electrical and mechanical data:
  • Standard: IEC 61076-2-104
  • Gender: male
  • Coding: A-code
  • Connection type: single ended cable
  • Orientation: straight
  • Connector contacts: brass with gold-plated
  • Coupling nut/screw: brass with nickel-plated screw
  • Wire termination: soldering
  • Wire gauge: 26AWG/0.14mm2
  • Ambient temperature: -25 to 80°C
  • Rated current: 1A
  • Rated voltage: 30V
  • Insulation resistance: ≥100mΩ
  • Contacts resistance: ≤5mΩ
  • IP rating: IP67
